Dedicated Cooling System

본문

▶ Dedicated Cooling System


<Features>

- Convenient maintenance through air cooling.

- Double type is a system that cools the high-frequency heater's main body with low heat generated and largely affected by water temperature and the working coil part with high heat generated and less affected by water temperature (safe even at high water temperature) separately. It is indigenously developed by Insung.

- All parts use SUS or brass and thus no rust is generated.

- Motor overheat protection device attached.

- Automatic operation possible if directly connected to Insung’s high-frequency heater.



Item Contents
Model IC-10S IC-20S IC-50SD
WATER TANK CAPACITY 20ℓ 40ℓ 60ℓ
COOLING TYPE RADIATOR-Air cooling
PUMP 1HP 2HP 3HP
OUTLET PRESSURE 4㎏/㎠ 6㎏/㎠ 10㎏/㎠
COOLING WATER VOLUME 20ℓ/min 40ℓ/min 60ℓ/min
